Lantronix SRS2F – Stand-alone RS232 Remotely Managed Media Converter

Lantronix

The SRS2F Series stand-alone serial RS232 to fiber converters allow you to extend the distance between serial connections with the use of fiber optic cable. These full-featured stand-alone converters transmit the full complement of RS232 flow control and handshaking signals optically and support full or half-duplex asynchronous data transmission at speeds up to 115 Kbps.

د.إ0.00

Overview

Stand-alone RS232 Remotely Managed Media Converter
RS232 Copper to Fiber
The SRS2F Series stand-alone serial RS232 to fiber converters allow you to extend the distance between serial connections with the use of fiber optic cable. These full-featured stand-alone converters transmit the full complement of RS232 flow control/handshaking signals optically and supports full or half-duplex asynchronous data transmission at speeds up to 115 Kbps. Link a remote terminal to a host computer: Connect multiple devices, such as security scanners, POS devices, remote terminals and building access/alarming systems to a host computer. Ideal for campus or business environments where remote devices can be networked in a point-to-point configuration where distances are greater than the 15 meter limitation of conventional copper serial cables.
In addition, these stand-alone media converters can also be managed from remote locations, in-band, over the fiber, when linked to a CRS2F Series installed in a managed Point System™ chassis.
Features:
• Remote Management
• Local or Remote Loopback on copper and fiber
• DTE/DCE switch for easy installation with straight-through cabling
• Full/Half-duplex asynchronous transmission at speeds up to 115 Kbps
• Supports the following flow control signaling:
1. DCD – Data Carrier Detect
2. RXD – Receive Data
3. TXD – Transmit Data
4. DTR – Data Terminal Ready
5. SG – Signal Ground
6. DSR – Data Set Ready
7. RTS – Request To Send
8. CTS – Clear To Send

Specification

Standards
• EIA/TIA-574
• EIA/TIA RS-232E
Data Rate
• 115 Kbps

Switch
• DTE/DCE: Select appropriate position
• Loopback: Norm = normal operation;
• Loop = Fiber and copper loopback
Status LEDs
• P: (Power): Lit for normal operation
• RX: Steady = Copper Link;
• Flashing = Rx Data
• FL: Steady = Fiber Link;
• Flashing = Loopback mode

Dimensions
• Width: 3.3” [84 mm
• Depth: 4.8” [122 mm]
• Height: 1.2” [30 mm]
Power Consumption
• 5 Watts
Power Supply
• External AC/DC; 12 VDC, 0.5A min output; 120-240VAC input
Environment
• Operating: 0°C to 50°C
• Humidity: 5% to 95% (non-condensing)
• Altitude: 0 – 10,000 ft.
Weight
• 2 lbs. [0.90 kg]
Compliance
• Safety: Wall Mount Power Supply: UL Listed and CSA certified
• Emissions: CISPR22/EN55022 Class A + EN55024, EN60950 Class A, FCC Class A, CE Mark

Warranty
• Lifetime
