Specification
Mobile module : 4G (LTE) – Cat 4 up to 150 Mbps, 3G – Up to 42 Mbps, 2G – Up to 236.8 kbps
Wireless mode :IEEE 802.11b/g/n, Access Point (AP), Station (STA)
WAN :1 x WAN port 10/100 Mbps, compliance IEEE 802.3, IEEE 802.3u standards, supports auto MDI/MDIX
LAN : 3 x LAN ports, 10/100 Mbps, compliance IEEE 802.3, IEEE 802.3u standards, supports auto MDI/MDIX
VPN : Multiple clients and a server can run simultaneously, 27 encryption methods
MODBUS TCP SLAVE
MONITORING & MANAGEMENT
IOT PLATFORMS
Input voltage range : 9 – 30 VDC.
Ethernet : 4 x RJ45 ports, 10/100 Mbps
SIM : 2 x SIM slots (Mini SIM – 2FF), 1.8 V/3 V, external SIM holders, eSIM (Optional).
Dimensions (W x H x D) : 110 x 50 x 100 mm.
Operating temperature : -40 °C to 75 °C
